Basic free charging setup

When dealing with new equipment, all you might want to do is set up the most basic configuration so that you can test out some of the main features.
This guide shows how to do that.

When familiarizing yourself with the Charge Controller, you may want to set it up to allow charging easily without authorization or billing.
This makes testing the basic charging flow straightforward.
This guide shows you how to set that up.

1. Requirements

Make sure that

2. Enabling basic Free Charging

  1. Log in to the Config UI using the Operator Login Credentials
  2. In the Config UI, under AUTHORIZATION > Free Charging, set Free Charging to On (see more on free charging here)
  3. Below the parameter Free Charging , a new parameter Free Charging Mode appears. Select the No OCPP option (default)
  4. At the bottom of the Config UI, click , then click to apply the changes
Some caveats

With this setup,

  • The Charging Station will not be connected to a Backend
    • EV Owners will not be able to check if the Charging Station is occupied

3. Observing the charging session

  1. Log in to the Config UI using the Operator Login Credentials
  2. Connect an EV to the Charging Station (charging should start automatically)
  3. In the Config UI, under DASHBOARD, you can observe the current charging info:

#

4. What's next?

See here on all possible charging modes and a more in-depth guide on Free Charging.
