Monitor electrical systems with SmartDetect residual current monitors

Customised solutions for every electrical system

Today, modern electrical systems are often monitored using residual current measurement technology in order to detect insulation faults at an early stage and prevent failures.

With the new SmartDetect residual current monitors from Bender, this is now even better, more accurate and more flexible. The devices are equipped with state-of-the-art measurement technology and are easy to install, configure and operate. The existing Modbus RTU interface guarantees simple integration into the BMS and the compact design ensures that the devices fit into any control cabinet.

Design the future
of energy

Residual current monitors for the highest demands

RCMS410

Most important features

  • 4 channels
  • AC, pulsed DC, or AC/DC sensitive measuring
  • LED bargraph
  • External power supply
  • 18 mm wide

Other features

  • Measuring range: 2 mA … 70 A
  • Frequency range: DC … 20 kHz
  • Separate evaluation of AC, DC, RMS
  • DIN EN IEC 62020-1



To product page

RCMS425-L

Most important features

  • 4 channels
  • AC, pulsed DC, or AC/DC sensitive measuring
  • LED bargraph
  • Internal power supply
  • 36 mm wide

Other features

  • Measuring range: 2 mA … 70 A
  • Frequency range: DC … 20 kHz
  • Separate evaluation of AC, DC, RMS
  • DIN EN IEC 62020-1



To product page



RCMS425-D

Most important features

  • 4 channels
  • AC, pulsed DC, or AC/DC sensitive measuring
  • LCD display
  • Internal power supply
  • 36 mm wide

Other features

  • Measuring range: 2 mA … 70 A
  • Frequency range: DC … 20 kHz
  • Separate evaluation of AC, DC, RMS
  • DIN EN IEC 62020-1



To product page

NFC interface

For parameterising the measuring devices with the Bender Connect App

Modbus RTU interface

For simple connection to the building management system

Only a few operating elements

For easy installation and commissioning

Parameterisation via Bender Connect App

Even in dismantled and de-energised state

The most important benefits at a glance


  • Large measuring range
  • Measurement up to the 400th harmonic
  • Small and compact design

  • Easy installation
  • Simple commissioning
  • Parameterisation via smartphone app
  • Integration in BMS via Modbus RTU interface

Where SmartDetect residual current monitors are already in use

The Heide-Bäckerei Meyer in Wahrenholz has equipped its machines and systems with the latest monitoring technology from Bender. The aim is to avoid production downtimes. Watch the video (in German with English subtitles).
